Heel Pain

Main Causes of Heel Pain

Common causes of pain in various parts of the heel:

• BOTTOM of the heel: plantar fasciitis, plantar calcaneal bursitis, heel bruise, cracked heels
• BACK of the heel: Achilles tendonitis, retrocalcaneal bursitis, posterior heel spur, calcaneal apophysitis in children
• OUTER SIDE of the heel: lateral plantar nerve entrapment, an injury of the peroneal tendon, sciatica
• INNER SIDE of the heel: tarsal tunnel syndrome

In most cases, heel pain is caused by repeated prolonged walking, running or jumping and wearing improper shoes. According to one source, the left heel is typically the first to be affected ⁽³⁷⁾.

Severe heel pain can be caused by a rupture of the Achilles tendon or plantar fascia, heel fracture and nerve entrapment.

Explanation of medical terms:

• Calcaneus = heel bone
• Plantar = relating to the sole

1. Blisters and Corns

Blisters and corns are caused by constant pressure and rubbing by shoes. A blister is a minor skin damage with a localized fluid accumulation within the skin. Blisters on the bottom of the heels are usually painful and tender but they are not always visible. Corn (clavus, heloma) is a small (few millimeters) circular or conical skin thickening with a dark core ⁽³⁹⁾.

Do not try puncture a blister or cut corn on the bottom of the heel on your to avoid infection. A blister and corn can heal on its own but may not go away if the pressure continues. A custom heel insert with a hole at the site of pain, or debriding agents (salicylic acid, urea) can ease the healing and prevent pain ⁽³⁹⁾. A podiatrist can remove persistent corns.

2. Cracked Heels

Symptoms include cracked, thick, yellowish skin (callus) with deep fissures around the rim of the heel ⁽²⁵⁾.

Risk factors include dry skin, atopic dermatitis, diabetes mellitus, psoriasis, plantar keratoderma, hypothyroidism, obesity, wearing open-back-shoes, prolonged standing or walking.

You can get rid of cracked heels by using debriding agents, such as urea or salicylic acid.

A bandage, moisturizing creams or wearing heel pads or cups can help fix the problem.

Picture 1. Cracked heels
(source: DermNet NZ, CC license)

3. Plantar Fasciitis (Fasciosis)

Plantar fasciitis or fasciosis is an overuse injury of the plantar fascia–a band of the tissue that extends under the skin on the soles from the heel to the toes.

Symptoms include dull intermittent pain and tenderness on the inner, front side of the bottom of one or both heels or in foot arcs; pain is worse after rest, for example, after prolonged sitting or in the morning after getting out of bed. Pain increases over the months and can be relieved by few minutes of walking.

A typical sign is the pain triggered by upward flexion of the toes ⁽²⁴⁾.

Risk factors include wearing shoes with elevated and tight toe boxes, high arched feet, excessive foot pronation (inward rotation), flat feet or other foot anomaly, tight Achilles tendons, certain sports (golf, cycling), truck driving, sedentary lifestyle, muscle weakness after cast removal, old age, diabetes, rheumatoid arthritis, psoriatic arthritis, reactive arthritis, ankylosing spondylitis and fibromyalgia ^(4,12).

Triggers include prolonged standing, especially in overweight women after menopause or in pregnant women wearing unsupported footwear, prolonged repeated walking, running, jumping, walking upstairs or on tiptoes, pushing a heavy object and steroid injections.

Diagnosis can include a physical examination and ultrasound.

Treatment:

• Calf-stretching exercises
• Ice packs for 20 minutes before bed for 14 days, non-steroidal anti-inflammatory drugs for 6-8 weeks
• Calcaneal taping by kinesio tape (KT) ⁽⁴⁵⁾
• Some podiatrists recommend home remedies, such as soaking the affected feet in Epsom salt baths, but there seems to be lack of evidence of their effectiveness
• In severe cases: shoe padding with raised heels, foot strapping, custom orthotics, a night splint to keep a foot in an upward flexed position to prevent tightening, removable walking cast for few weeks, physiotherapy
  • Steroid injections (temporary relief)
  • Extracorporeal shock wave therapy (ESWT) ⁽⁴⁶⁾
  • Surgery called “plantar fascia release” or “partial plantar fasciotomy”

Prevention:

• Massage with two fingers along the foot arc 3 times for 1 minute with 30 seconds rest in between before making first steps in the morning ⁽⁴³⁾.
• Wear shoes with flat heels, high arc support insoles, wide toe boxes and flexible soles, making a hole in a shoe pad at the site of the tender spot.
• Avoid prolonged standing, walking and running or walking barefoot.

References: ^{(1,2,5,12,26)}

Picture 2. Plantar fasciitis – pain location
(source: Wikipedia, CC license)

4. Inferior (Plantar) Calcaneal Spur

Plantar heel spurs–the overgrowths of bone on the bottom of the heel–commonly develop in plantar fasciitis but only sometimes cause pain ⁽⁸⁾. If they do not cause pain they do not need to be removed. Surgical removal of a spur does not necessary relieve heel pain and can be associated with complications, such as bone infection or fracture ^(3,8).

Picture 3. Calcaneal spur – at the bottom of the heel
(source: Radiopedia, CC license)

5. Plantar Fascial Rupture (Tear)

• Symptoms and signs: sudden, sharp pain, tenderness, swelling or bruising on the inner side of the heel or foot arch; bruising can appear within few days.
• Cause: trauma
• Risk factors: flat feet, tight calf muscles
• Diagnosis: magnetic resonance imaging (MRI)
• Treatment: a short-leg nonweight-bearing cast and crutches for 4-6 weeks; surgery is rarely needed.
• References: ^(9,10)

6. Plantar Calcaneal Bursitis (Policeman’s Heel)

Plantar calcaneal bursitis is an inflammation of the fluid-filled sac on the bottom of the heel, which prevents friction between the heel bone and plantar fascia.

• Symptoms: throbbing pain, tingling, swelling, redness and tenderness in the middle bottom part of the heel that increases during the day and tend to be worse in the evening
• Causes: prolonged standing or walking, heel striking when running, blunt injury, arthritis
• Diagnosis: physical examination
• Treatment: rest from weight-bearing activities, ice packs, stretching exercises ⁽⁷⁾
• Prevention: shoes with flexible soles and wide toe boxes, heel cups, padded socks
• References: ^(7,11,13)

7. Heel Bruise (Stone Bruise)

When you repeatedly land with the heels on hard surfaces during running, you can bruise the fat pad under your heel bone, which causes pain, tenderness and swelling and, sometimes, bruising with visible discoloration ⁽³⁾. Treatment is similar as for plantar fasciitis. Prevention can include heel cups or donut-shaped cushions ⁽¹⁵⁾.

A puncture wound can also cause heel bruise.

8. Bone Bruise

Landing hard on the heel can cause bone bruise with blood accumulation in the heel bone and visible bruising of the soft tissues on the bottom of the heel. Diagnosis can be made by magnetic resonance imaging (MRI) ⁽¹⁶⁾. Treatment may include wearing a non-weight-bearing leg cast. Recovery time my be from several weeks to months ⁽¹⁶⁾.

9. Lateral Plantar Nerve Entrapment

The first branch of the lateral plantar nerve (Baxter’s nerve) enables sensation in the front of the heel.

• Symptoms of the nerve entrapment: sharp, shooting pain, burning or tingling in the front middle part of the bottom of the heel and, sometimes, behind the inner ankle, aggravated by standing or walking, worse in the evening
• Causes and risk factors: athletic activity, wearing shoes with minimal padding, flat feet, new arch supports
• Diagnosis: magnetic resonance imaging (MRI)
• Treatment: ice packs, oral painkillers, steroid injections, night splints or surgical decompression
• Prevention: heel cups or other orthotics
• References: ^(13,36)

10. Calcaneus (Heel Bone) Fracture

• Causes: fall from the height, car accidents, twisting injury
• Symptoms and signs: sudden, sharp pain, swelling, bruising, tenderness, heel deformity, inability to put weight on the heel
• Diagnosis: X-ray or CT
• Treatment:
  • Stable fractures without bone displacement need only non-weight bearing casting. The recovery time, during which you may not be able to put weight on the heel, is at least 6-8 weeks.
  • Unstable fractures with displaced bony parts require surgery; recovery time may be from few weeks to 1-2 years.
  • Physiotherapy can help to restore the mobility of the foot.
• Complications: infection, arthritis, chronic pain, bone collapse
• Reference: ⁽¹⁸⁾

Picture 4. Calcaneal fracture
(source: Wikipedia, CC license)

11. Stress Fracture

A stress fracture is a small “hairline” fracture within the bone in which the bone as a whole does not fall apart.

• Symptoms: heel pain that develops over days to weeks, is worse during weight-bearing and is relieved by rest
• Signs: tenderness upon medial-lateral compression of the heel bone
• Causes: overuse injury common in long-distance runners and distance jumpers
• Risk factors: osteoporosis, vitamin D deficiency ^(41,42)
• Diagnosis: technetium bone scan (bone scintigraphy) or magnetic resonance imaging (MRI); fresh stress fractures not visible on X-ray
• Treatment: ice packs, wearing cushioned shoes for 3 weeks and if no improvement, wearing removable cast boot for 6-8 weeks; fixation with screws (sometimes)
• Complications: complete fracture (when not resting carefully)
• References: ^(5,9,19)

Picture 5. Calcaneus stress fracture
(white line across the back part of the heel)
(source: Radiopedia, CC license)

12. Peripheral Neuropathy

Peripheral neuropathy means damage of the peripheral nerves.

Causes include diabetes mellitus, alcoholism, vitamin deficiencies, peripheral artery disease and injury.

Symptoms usually develop slowly in the symmetrical “stockings and gloves” pattern and may include stabbing pain, paresthesia (tingling, burning, extreme sensitivity or numbness) in the soles of the feet and weakness in arms and legs ^[17].

13. Other Causes of Pain On the Bottom of the Heel

Osteomyelitis is an infection of the bone.

• Symptoms: deep heel pain with muscle spasm, fever
• Causes and risk factors: puncture injury, surgery, systemic infection, diabetes mellitus
• Diagnosis: bone scan, MRI
• Reference: ^(6,24)

Bone cyst in the heel rarely causes pain.

Tumors:

• Neuroma–a benign tumor of the medial calcaneal nerve can present with a painful lump on the bottom of the heel ⁽²⁴⁾.
• Primary bone cancer (Ewing sarcoma), leukemia ⁽⁴⁰⁾ or metastatic cancers in the heel are rare ⁽²⁴⁾.

1. Blisters and Corns

See above

2. Achilles Tendinitis

Achilles tendinitis is an inflammation of the Achilles tendon, which connects the calf muscles to the heel bone.

Symptoms include pain on the back and above the heel, which can be present in the morning, can improve with mild exercise but worsen with continued exercise and by the pressure of shoes ^(5,27). In truck drivers, the right foot is more commonly affected.

Signs include swelling and warmth on the back of the heel, tenderness and intense pain upon squeezing the tendon from the sides during moving the foot upwards and downwards ^(24,27).

Causes include jumping (basketball, volleyball), cycling, poorly fitting shoes, constant pressure on the accelerator pedal in truck drivers, overpronation (inward foot rotation) ⁽²⁶⁾, ankylosing spondylitis, reactive arthritis, rheumatoid arthritis and gout.

Diagnosis is by a physical examination; MRI can reveal the extension of the damage.

Treatment can include rest from hard exercise, ice packs, immobilization, night splints, oral painkillers, wearing open-back shoes, heel lifts or cups; massage and stretching exercise after the pain goes away and ultrasound therapy ^(27,28). Steroid injections are not recommended because of the risk of tendon rupture ⁽⁵⁾. In severe cases, surgical removal of the abnormal tissue may be needed.

Picture 6. Achilles tendinitis
(source: Orthopedia Wiki, CC license)

3. Achilles Tendon Rupture

• Causes: sudden acceleration, forceful jumping
• Symptoms: acute intense pain on the back of the heel, a popping sensation, difficulty walking uphill or upstairs
• Signs: swelling on the back of the heel, difficulty raising the toes
• First aid: RICE (Rest, Ice, Compression, Elevation)
• Diagnosis: physical examination
• Treatment:
  • Partial rupture: a cast or brace
  • Complete rupture: surgery
  • Recovery time: 4-6 months ⁽³⁰⁾
• Reference: ⁽²⁹⁾

Picture 7. Achilles tendon rupture
(source: Physiopedia, CC license)

4. Retrocalcaneal Bursitis

Retrocalcaneal bursitis is an inflammation of a fluid-filled sac–bursa–that lies between the heel bone and the Achilles tendon ⁽³⁾.

• Symptoms: pain on the back of the heel that is worse in the morning, and a red, swollen, soft, tender bump behind your heel
• Causes: running, irritation by shoes, switching from high heels to flat shoes
• Treatment can include resting from irritating activities, non-steroidal anti-inflammatory drugs (ibuprofen), steroid injections, heel inserts, Achilles tendon stretching exercises, ice packs or surgical removal of bone spurs
• Prevention: wearing open-back shoes or special heel cups that prevent irritation of the back of the heel
• References: ^(3,13,14)

Picture 8. Retrocalcaneal bursitis
(source: Osmo Patch, by permission)

5. Posterior Heel Spur (Pump Bump, Haglund’s Deformity)

A posterior heel spur is a bone overgrowth on the back of the heel bone.

• Symptoms: a noticeable hard bump, pain, swelling and redness (due to retrocalcaneal bursitis) on the back of one or both heels
• Causes: wearing high heels or pump shoes, ice skates or any type of shoes with a rigid back
• Risk factors: high-arched feet (pes cavus), tendency to walk on the outside of the heel (varus heel), tight Achilles tendon, osteoarthritis
• Diagnosis: X-ray can show a bony spur near the Achilles tendon.
• Treatment: ice packs, oral painkillers, avoiding long walks, wearing open-back shoes, heel lifts or custom arc support, stretching exercises or, rarely, a cast or surgery
• Reference ⁽³³⁾

Picture 9. Posterior heel spur
Red arrow: bone spur
Green arrow: Achilles tendon calcification
(source: Orthopedics One, CC license)

6. Calcaneal Apophysitis (Sever’s Disease) in Children

Calcaneal apophysitis refers to irritation of the center of the heel bone due to athletic activity, obesity or poorly fitting shoes, mostly in boys 6-14 years of age ^(4,9).

• Symptoms: the bottom back part of the heel can be sore and tender but usually not swollen, upward flexion of the foot worsens the pain and walking on the toes relieves it
• Prevention: heel cushions
• Treatment: rest from intense physical activities, ice massage, painkillers; when pain decreases: stretching
• References ^(4,9)

7. Retrocalcaneal Spur Syndrome

• The main risk factor is equinus foot deformity
• Symptoms: pain, redness and thickening of the Achilles tendon at its insertion on the back of the heel
• Therapy: physical therapy or surgery
• Reference ⁽³¹⁾

8. Arthritis

Arthritis is a rare cause of chronic heel pain.

Rheumatoid arthritis symptoms include symmetrical joint pain and stiffness in fingers, toes, knees or other joints, subcutaneous nodules on the soles and bunions (bunny bumps at the bases of the big toes) ⁽²³⁾.

Psoriatic arthritis symptoms: scaly skin and pain in the shoulder, elbow, hip, fingers, knee and on the back of the heels on one or both sides ⁽²²⁾.

Reactive arthritis or Reiter’s disease symptoms in young men: symmetrical pain in the knees, ankles and on the back of the heels, inflamed eyes and burning urination ⁽²¹⁾.

Gout symptoms: sudden, severe painful attack in the big toe, which is usually red, hot and swollen; other possible painful spots: heel, ankle, knee, wrist, usually only on one side ⁽²⁰⁾.

9. Bottom Heel Pain in ELDERLY

Overload heel pain syndrome with or without heel pad atrophy in older or obese individuals includes diffuse pain limited to the bottom of the heel; upward flexion of the toes does not trigger pain ^(24,44). Repeated steroid injections can also result in heel pad atrophy. Losing weight, avoiding prolonged standing and wearing soft shoe pads can help prevent pain.

Paget’s disease is a chronic disease with abnormal bone remodeling. Symptoms include pain and tingling in the heel but usually no tenderness. Diagnosis is by MRI. Treatment may include painkillers, bisphosphonates or surgery ^(34,35).

Women who wear high heels, pump shoes, sandals or other footwear without firm structure are more likely to have heel and knee pain later in life ⁽⁷⁾.

1. Sciatica

Sciatica is pain caused by compression of the L5-S1 spinal nerve root, usually due to a bulging or herniated disc.

Symptoms may include pain, tingling or numbness in the lower back, buttock, back of the thigh, in the calf, outer side of the heel and foot and in the pinky and 4th toe, usually only on one side. Pain is often aggravated by sitting and relieved by walking ⁽⁹⁾.

Picture 10. Sciatica pain location in the foot:
blue, violet and green area
(source: Wikipedia, CC license)

2. Peroneal Tendon Injuries

• Causes: ankle sprain, tendon subluxation
• Symptoms: pain and swelling behind and below the outer ankle, instability of the ankle
• Signs: tenderness on the outer side of the foot below and in front of the ankle; upward flexion of the toes triggers pain behind/below the outer ankle.
• References ^(24,38)

1. Tarsal Tunnel Syndrome

Tarsal tunnel syndrome is caused by the compression of the posterior tibial nerve on its course behind the inner ankle.

Symptoms include pain, burning, tingling or numbness below the inner ankle and on the inner side of the bottom of the foot.

Signs:

• Tinel’s sign. Tapping behind the ankle can trigger pain that radiates toward the toes.
• Pushing the toes up triggers pain behind the inner ankle.
• The bottom of the heel is usually not tender.

Causes include previous ankle fracture or inflammation of muscle tendons; pain can be triggered by standing or walking after prolonged period of rest.

Therapy can include correction of eventual excessive pronation, physical therapy or surgical decompression.

References: ^(5,9,24)

2. Baxter’s Nerve Entrapment

See above

3. Posterior tibial tendonitis

Posterior tibial tendonitis is inflammation of the muscle tendons that run behind and below the inner ankle. It can cause tenderness below and behind the inner ankle and in the middle of the inner side of the foot ⁽²⁴⁾.

Treatment of most causes of heel pain can include:

1. Rest from the activities that cause pain.

2. Ice packs wrapped in a towel for 20 minutes several times a day can reduce pain and inflammation.

3. Oral painkillers, usually non-steroidal anti-inflammatory drugs (NSAIDs), such as aspirin, ibuprofen or naproxen.

4. Appropriate shoes:

• Wide toe boxes, flat heels, flexible soles and soft upper edges
• Open-back shoes for the pain on the back of the heel
• Heel lifts or cups and cushion pads for the pain on the bottom of the heel

5. Orthoses:

• Night splints to maintain the foot in an upward flexed position (90°) in plantar fasciitis and Achilles tendonitis
• A non-weight bearing, non-removable cast and crutches for a heel fracture
• A removable cast for plantar fasciitis, plantar calcaneal bursitis or stress fracture

6. There is insufficient evidence of the effectiveness of acupuncture and botulinum toxin injections in the treatment of heel pain.

Stretching Exercises

Calf-stretching exercises strengthen the Achilles tendon and can help prevent pain in plantar fasciitis, Achilles tendonitis and in plantar and retrocalcaneal bursitis.

Stand 40 cm away from the wall with one foot in front of other and with hands on the wall and lean forward while having the front leg bent at the knee and the back leg straight. Hold for 10 seconds and repeat 10 times with each leg every day for 6-8 weeks.

Sit on the floor with your legs straight forward. Loop a towel around the ball of the foot and pull it toward you and hold for few seconds. Repeat 10 times with each foot several times a day.

Stand on the bottom step of the stairs with only toes, lower your heels and hold for 30 seconds; repeat 10 times during the day.

Roll your foot over a rounded can back and forth for few minutes before going to bed in the evening and before making the first steps in the morning.

Video 1. Common types of heel pain with pain locations

• References

  1. Heel Pain (Plantar Fasciitis)  Foot Health Facts
  2. Plantar fasciitis  Patient.info
  3. Heel Pain  American Orthopedic Foot and Ankle Society
  4. Heel pain  Drugs.com
  5. Heel pain  Patient.info
  6. Nordquist C, What is heel pain? What causes heel pain?  Medical News Today
  7. Paddock C, 2009, Wearing High Heels, Pumps And Sandals Linked To Women’s Foot Pain In Later Life, Study  Medical News Today
  8. Green D et al, 2006, Plantar Calcaneal Spurs: Is Surgery Necessary?  Podiatry Today
  9. Barrett S et al, 1999, Plantar Fasciitis and Other Causes of Heel Pain  American Family Physician
  10. Plantar Fascia Rupture  Foot Education
  11. Bursitis (Infracalcaneal)  Northwest Foot and Ankle
  12. Plantar Fasciosis  Northwest Foot and Ankle
  13. Heel Pain and the Proper Diagnosis  Family Foot Care, PC
  14. Retrocalcaneal Bursitis Treatment and management  Emedicine
  15. Zeigler T, Bruised Heel (Fat Pad Contusion)  SportsMD.com
  16. Dienst M et al, 200, Bone bruise of the calcaneus. A case report  PubMed
  17. Peripheral Neuropathy Fact Sheet  National Institute of Neurological Disorders and Stroke
  18. Calcaneus (Heel Bone) Fractures  OrthoInfo
  19. Stress Fractures of the Foot and Ankle  OrthoInfo
  20. What is gout?  National Institute of Arthritis and Musculoskeletal and Skin Diseases
  21. Questions and Answers about Reactive Arthritis  National Institute of Arthritis and Musculoskeletal and Skin Diseases
  22. Psoriatic arthritis  American College of Rheumatology
  23. Rheumatoid Arthritis in the Foot and Ankle  Foot Health Facts
  24. Diagnosing Heel Pain in Adults  American Family Physician
  25. Cracked heels  DermNet NZ
  26. Pronation and Orthotics  University of California, San Francisco; Sports Medicine
  27. Achilles Tendinitis  American Orthopedic Foot and Ankle Society
  28. Common Disorders of the Achilles Tendon  Foot Health Facts
  29. Achilles Tendon Rupture  Foot Health Facts
  30. Achilles tendon rupture treatments and drugs  Mayo Clinic
  31. Martin DE, POSTERIOR CALCANEAL OSTEOTOMY: A Surgical Alternative for Chronic Retrocalcaneal Pain  The Podiatry Institute
  32. Heel Spur (Calcaneal)  Disability Guidelines
  33. Haglund’s Deformity  Foot Health Facts
  34. Paget’s disease of bone  OrthoInfo
  35. Patel P et al, 2012, Paget’s disease of the calcaneus causing right foot pain  PubMed Central
  36. Toye L, 2012, Baxter’s Nerve (First Branch of the Lateral Plantar Nerve) Impingement  Radsource.us
  37. Heiring M, Heel Pain FootVitalis
  38. Peroneal Tendon Injuries  Foot Health Facts
  39. Corns and calluses  DermNet NZ
  40. Lovell WW et al, 2006  Lovell and Winter’s Pediatric Orthopaedics, 6th Edition, Volume1, p.129
  41. McCabe MP et al, 2012, Current concept review: vitamin D and stress fractures  PubMed
  42. Vitamin D Deficiency  Foot Health Facts
  43. Schwartz EN, 2014, Plantar Fasciitis: A Concise Review  PubMed Central
  44. Overload Heel Pain Syndrome  Foot Education
  45. Hyland MR et al, 2006, Randomized controlled trial of calcaneal taping, sham taping, and plantar fascia stretching for the short-term management of plantar heel pain    Journal of Orthopaedic & Sport and Physical Therapy
  46. Weil JS Jr et al, 2002, Extracorporeal shock wave therapy for the treatment of chronic plantar fasciitis: indications, protocol, intermediate results, and a comparison of results to fasciotomy  PubMed
